4 Port GEPON L3 OLT Without PON Module
Product Details:
- Product Type 4 Port GEPON L3 OLT Without PON Module
- Dimension (L*W*H) 442 x 200 x 43 Millimeter (mm)
- Weight 3.2 Kilograms (kg)
- Click to View more
4 Port GEPON L3 OLT Without PON Module Price And Quantity
- 40710 INR/Unit
- 1 Unit
4 Port GEPON L3 OLT Without PON Module Product Specifications
- 442 x 200 x 43 Millimeter (mm)
- 4 Port GEPON L3 OLT Without PON Module
- 3.2 Kilograms (kg)
Product Description
4 Port GEPON L3 OLT Without PON Module is 1U height 19 rack mount device. The features of this type of module are compact, flexible, easy to deploy, convenient, and high performance. It is ideal to be installed in small room environment. It can also be utilized for Triple-Play, IP Camera, VPN, and Enterprise LAN applications. Moreover, 4 Port GEPON L3 OLT Without PON Module is checked by expert quality controllers to guarantee constant performance, high efficiency, low maintenance need, and cost-effectiveness.
Specifications:
| AC Power Supply | AC: 90- 264 V, 47/63 Hz |
| Number Of Ports/Pins | 4 |
| Model Name/Number | OP100P4 |
| Broadcasting Media | FTTH |
| Brand | Optronix |
| Weight | 3.2 Kg |
| Working Temperature | 0 - +50 C |
| Wavelength | TX 1490nm, RX 1310nm |
| Transmission Distance | 20 Km |
| TX Power | +2-+7 dBm (PX20+) |
| Storage Temperature | -40 - +85 C |
| Saturation Optical Power | -6dBm |
| Rx Sensitivity | -30dB (PX20+) |
| Relative Humidity | 5-90% (non-conditioning) |
| PON Port Connector | SC/UPC |
| Max Power Consumption | 30 W |
| Management Ports | 1 x 10/100 BASE-T out-band port, 1 x CONSOLE port |
| Fiber Type | 9/125 micron m SMF |
| EPON port speed | Upstream 1.25G, Downstream 1.25G |
| EPON Port Qty | 4 |
| EPON Port Physical Interface | SFP Slot |
| EPON Port Max splitting ratio | 1:64 |
| EPON Port Connector Type | PX20+ |
| Dimension | 442 x 200 x 43 mm |
| Chipset | Broadcom |
| Chassis Rack | 1U 19" standard box |
| Chassis Qty | 8 |
Functional Characteristics:
Satisfactory Standard:
- Meet ITU-T G984/G.988 standards
Support IPv6 Function
- Support DN, IPv6 Ping, IPv6 Telnet
- Support ACL based on source IPv6 address, destination IPv6 address, L4 port, protocol type, etc.
- Support MLD v1/v2 snooping
IP route
- Support static route, dynamic route RIP v1/v2, OSPF v2
Easy to manage
- Friendly EMS/Web/Telnet/CLI/SSH management
- CLI command style similar to mainstream manufacturers
Fully open platform
- Open to any brand of ONU
High performance cost
- 1U height compact design
- Adopt mainstream chip scheme
